Cu-Metallized Diamond
Thermal + Electrical Integration

Cu-Metallized
Single Crystal Diamond

Extreme thermal conductivity combined with precision electrical routing. Custom trace layouts for direct die attachment and multi-chip power modules.

Heat Removal + Power Delivery in One

Copper metallization enables direct die attachment and electrical routing while diamond handles extreme thermal loads.

Standard and Custom Form Factors

Round, square, or octagonal baseplates in standard and custom shapes. Custom DFM available for CPO switches, optical engines, and laser submounts.

Custom Cu Trace Routing

Custom copper plating and trace routing. NRE required for custom masking. Other metals available for specialized requirements.

>2200 W/m·K Thermal Conductivity

Single-crystal diamond base instantly removes junction heat, extending laser lifespan and increasing optical output power limits.

Metallization Options

Custom Metal Systems

Our Cu-metallized SCD substrates are engineered for extreme-density AI hardware. Custom trace layouts allow direct die attachment while drawing away devastating heat loads.

Standard Configuration

  • Copper (Cu): Primary metallization for thermal and electrical performance
  • Other metals available: Au, Pt, Pd, Ag, W — contact us for custom metallization requirements.

Specifications

Base Diamond
Material Single Crystal Diamond (SCD)
Thermal Conductivity >2200 W/m·K
Metallization
Primary Metal Copper (Cu)
Other Options Au, Pt, Pd, Ag, W
Custom Routing NRE for custom masking
Geometry
Shapes Round, Square, Octagonal
Custom Routing Available on request
Matched Parts & Applications

Built for Extreme-Density AI Hardware

From CPO switches to laser arrays, our Cu-metallized substrates enable next-generation power delivery and thermal management.

CPO Switch Baseplates

51.2T/102.4T network switch ASICs

Cu-plated SCD baseplates provide identical CTE and sub-0.1K temperature uniformity across the entire switch, maintaining absolute optical alignment while providing electrical routing for drivers.

High-Density Power Delivery Networks

48V to 1V multi-chip power conversion

Cu-metallization allows direct AuSn soldering of multiple power diodes and MOSFETs onto a single diamond plane. Shrinks footprint by allowing tight component packing without thermal cross-talk.

ELSFP Laser Submounts

CW laser arrays for CPO external light sources

Copper traces enable multi-channel electrical driving of dense EML/DML laser arrays while the SCD base instantly removes junction heat, extending laser lifespan and increasing optical output power limits.

Standard configurations and dimensions are partner-level

Sign in to see the most frequently manufactured Cu-Met configurations, dimensions, and metallization options. Custom DFM is available for any geometry.

Contact us Sign up for newsletter
Partner-only content

Sign in to see the wafer-scale qualification table and Custom DFM options for non-standard footprints.

Contact us Sign up for newsletter

Tell us your target layout

Tell us your target dimensions, electrical routing requirements, and quantity — we'll respond with a Custom DFM plan and a quote within 48 hours.
